Traffic direction ACL parameter ACL value Description
Egress All allowed services
from any IP address to
any local subnet
Permit This traffic is tunnelled using
VPN
Egress Default Deny -
Simple VPN topology example
crypto isakmp policy 1
encryption aes
hash sha
group 2
exit
crypto isakmp peer address <Main Office Public Internet Static IP Address>
pre-shared-key <secret key>
isakmp-policy 1
exit
crypto ipsec transform-set ts1 esp-3des esp-sha-hmac
set pfs 2
exit
crypto map 1
set peer <Main OfficeMain Office Public Internet Static IP
Address>
set transform-set ts1
exit
ip crypto-list 901
local-address <Branch Office Public Internet Static IP Address>
ip-rule 10
source-ip <Branch Subnet1> <Branch Subnet1 Mask>
destination-ip any
protect crypto map 1
exit
ip-rule 20
source-ip <Branch Subnet2> <Branch Subnet2 Mask>
destination-ip any
protect crypto map 1
exit
exit
ip access-control-list 301
ip-rule 10
source-ip any
destination-ip any
ip-protocol udp
udp destination-port eq Ike
composite-operation Permit
exit
ip-rule 11
source-ip any
destination-ip any
ip-protocol udp
udp destination-port eq Ike-nat-t
composite-operation permit
exit
ip-rule 12
source-ip any
destination-ip any
ip-protocol udp
udp destination-port eq Ike-nat-t-vsu
composite-operation permit
exit
ip-rule 20
IPSec VPN
Administering Avaya G430 Branch Gateway October 2013 507
