Troubleshooting Guidelines
62 9600 Series H.323 Deskphones Release 6.0 Installation and Maintenance Guide
L3 Audio nn DSCPAUD; Differentiated Services Code
Point for audio.
L3 Signaling nn DSCPSIG; Differentiated Services Code
Point for signaling.
Scroll Right to see the following additional parameters/values:
Ethernet Text string corresponding to PHY1STAT
value, for example, “auto,” “100Mbps HDX,”
1000Mbps FDX.”
PC Ethernet Test string corresponding to PHY2STAT
value, for example, “disabled,” “100Mbps
HDX,” 1000Mbps FDX.”.
Scroll Right to see the following additional parameters/values:
Model 96ccDccc Up to 8 ASCII characters: MODEL serial
number.
Phone SN cccccccccccccccccc Telephone Serial Number, up to 18 ASCII
characters.
PWB SN cccccccccccccccccc Printed Wiring Board (circuit board) Serial
Number, up to 18 ASCII characters. Applies
only to 96xx IP Deskphones that have a
software-readable PWB serial number and
comcode.
PWB comcode nnnnnnnnn 9 ASCII numeric characters. Applies only to
96xx IP Deskphones that have a
software-readable PWB serial number and
comcode.
MAC address hh:hh:hh:hh:hh:hh Each octet of the MAC address displays as
a pair of hexadecimal numbers.
Group nnn Up to 3 ASCII numeric characters: GROUP
value.
Protocol: cccccccc Up to 8 ASCII characters, currently only
“H.323.”
Application File filename.ext 4 to 32 ASCII characters (primary
application).
Table 2: Parameter Values (continued)
Name System Value Format
2 of 3
