IFD500 Series Pilot Guide
4-66 Map Subsystem
The Charts Selection page presents a list of available charts. Use
the right-hand knob on the IFD to select the desired approach from
the presented list and push the knob in, or touch the desired
approach in the list, to select and display the chart.
NOTE
Inclusion of RNP Approach Choices
RNP AR (authorization required) approaches may be
included in the list of available charts and can be
selected for viewing but they cannot be selected in the
FMS, and the IFD system is not authorized for RNP AR
operations.
EUROPEAN VISUAL APPROACH, LANDING AND AREA CHARTS
European VFR charts (formerly referred to as “Bottlang Charts”) are
also available as an optional JDM download package (requires
Release 10.2.0.0 or later). If they are part of your Chart subscription
package, then they will appear in the directory list with the term
“VFR” in the chart title.
Sample VFR Area Chart
