Note that selecting any of these presets only affects map layers,
not the other map settings such as compass rose on/off, airport
filter on/off, etc.
Factory Settings
Factory settings for map layers are as follows:
Layer
Visible
Labels
Range
Detail
Alt Filter
SUA
On
160
Hi
VOR
On
On
160
Low
Towered Apts
On
On
100
Low
NonTowered Apts
On
On
80
Med
Class A/B/C
On
100
Med
> 0
Class D
On
30
Hi
< 2000
High Obstacles
On
On
50
Med
< 1500
Low Obstacles
On
On
40
Hi
< 1500
Intersections
Off
Off
40
Hi
Victor Airways
On
On
50
Med
< 19000
Jet Airways
Off
On
50
Hi
>= 17000
VFR Waypoints
Off
Off
40
Hi
NDBs
Off
Off
50
Hi
Flight Plan
On
Non-TA Traffic
On
40
n/a
Power Lines
On
10
n/a
< 1500
Interstates
On
On
100
n/a
IFR Settings
IFR settings for map layers are the same as factory settings
except for the following changes:
Layer
Visible
Labels
Range
Detail
Alt Filter
NonTowered Apts
50
Low Obstacles
50
Intersections
On
On
30
Victor Airways
40
Jet Airways
On
NDBs
On
On
Interstates
30
