Spare Parts Lists AVL 4000
8-2 Service Manual
8.2 Standard List
This spare parts list applies to the following instruments:
• AVL DiGas 4000
• AVL DiSmoke 4000 with Opacity Measuring Chamber 4000
• AVL DiCom 4000 with Opacity Measuring Chamber 4000
EVALUATION UNIT 4000
DONGLE for 4000 E321.00./B00.0 BV2150
TEMPERATURE CABLE 4330V10./B00.0 BV2055
POWER SUPPLY CABLE 4330V03./B00.0 BV1981
REMOTE CONTROL CABLE 4330V08./B00.0 BV2022
COPPER ADHESIVE TAPE W=12.7 MM HB0187
DISPLAY COMPLETE 4330W07./B00.0 BO2470
DISPLAY LCD 320X240 DOT HOSIDEN EL0277
DISPLAY LCD 320X240 DOT HITACHI EL0285
SPACER M3 L=50mm INSIDE WIDTH=8 EP0321
SPACER PIN V5737A EP0052
HOUSING COVER 4330U01./B00.0 ZG1923
MEMBRANE KEYPAD 4000L 4330K05A/B00.0 ZI0053
FOOT PAD ORDER NO. 921-1024-000 DF0034
LOCK 4330U10./B00.0 ZG1929
4000 MAIN BOARD
CONSISTING OF:
1 MAIN BOARD 4630A01./B00.0
TD4000MBA.01
BA0885
PCMCIA CARD 4MB EN0339
PLUG PANEL 4330U02./B00.0 ZG1924
METALLIZED POLYESTER FOIL SK0237
POWER SUPPLY UNIT 5/8A 24/2A +15,-15/2.5A EN0321
PRINTER COVER 4330K03./B00.0 RM0141
PRINTER COVER SHAFT 4330U11./B00.0 ZG1936
EXPANDED RUBBER DISPAY EURO 4330U27./B00.0 ZG2025
BOTTOM SUPPORT 4330U07./B00.0 ZG1933
PRINTER COVER SUPPORT 4330U05./B00.0 ZG1935
TOP SUPPORT 4330U06./B00.0 ZG1932
