10-4

Chapter 10. MAINTENANCE AND TROUBLESHOOTING



Behavior in case of RSP input failure

When an alarm occurs, all actions are continued.

The following table shows the indications and alarms of this unit if RSP input

failure occurs:

Failure status Range No. Indication value Alarm code

Burnout 0 (4 to 20 mA) Downscale (-10 %FS)

AL06

1 (0 to 20 mA) Indefiniteness (around

0 %FS)

None

2 (0 to 5 V) Downscale (-10 %FS)

AL06

3 (1 to 5 V) Downscale (-10 %FS)

AL06

4 (0 to 10 V) Downscale (-10 %FS)

AL06
