Chapter 5. DETAILED DESCRIPTION OF EACH FUNCTION
It is possible to set the AUTO/MANUAL mode selection, RUN/READY mode selection, LSP/RSP mode
selection, Auto Tuning (AT) stop/start selection, release all digital output (DO) latches, and OFF/ON selection of
communication digital input 1 (communication DI 1).

AUTO/MANUAL mode
The AUTO/MANUAL mode selection can be set.
Item (Bank) Display Contents Initial value User level
AUTO/MANUAL
mode selection
(Mode bank)
AUtO
: AUTO mode [Communication value is "0".]
MAn
: MANUAL mode [Communication value is "1".]
AUtO
Basic,
Standard,
High function
• When the AUTO/MANUAL mode is changed, the display is automatically
returned to the operation display.
• If the operation type of internal contacts 1 to 5 is set at “AUTO/MANUAL”,
[
A--M
: AUTO/MANUAL mode selection] can be displayed, but the setting
cannot be configured.
• When [
CtrL
: Control method] is set at "0" (ON/OFF control), [
A--M
: AUTO/
MANUAL mode selection] cannot be displayed and set.
• When [
bit 0
: AUTO/MANUAL display] of [
C73
: MODE display setup] is set at "0"
(no display), [
A--M
: AUTO/MANUAL mode selection] cannot be displayed and
set.

RUN/READY mode
The RUN/READY mode selection can be set.
Item (Bank) Display Contents Initial value User level
RUN/READY mode
selection
(Mode bank)
rUn
: RUN mode [Communication value is "0".]
rdy
: READY mode [Communication value is "1".]
rUn
Basic,
Standard,
High function
• If the operation type of internal contacts 1 to 5 is set at “RUN/READY”, [
r--r
:
RUN/READY] can be displayed, but the setting cannot be configured.
• When [
bit 1
: RUN/READY display] of [
C73
: MODE display setup] is set at "0" (no
display), [
r--r
: RUN/READY mode selection] cannot be displayed and set.

LSP/RSP mode
The LSP/RSP mode selection can be set.
Item (Bank) Display Contents Initial value User level
LSP/RSP mode
selection
(Mode bank)
LSP
: LSP mode [Communication value is "0".]
RSP
: RSP mode [Communication value is "1".]
LSP
Basic,
Standard,
High function
• If the operation type of internal contacts 1 to 5 is set at “LSP/RSP”, [
L--r
: LSP/
RSP mode selection] can be displayed, but the setting cannot be configured.
• When [
bit 2
: LSP/RSP display] of [
C73
: MODE display setup] is set at "0" (no
display), [
L--r
: LSP/RSP mode selection] cannot be displayed and set.
• If the model does not have the RSP mode, [
L--r
: LSP/RSP mode selection] cannot
be displayed and set.
5 - 2 Mode
