Azbil C35 Series User Manual

6-3
Chapter 6. LIST OF DISPLAYS AND SETTING DATA
6 - 2 List of Parameter Setting Displays
The following shows the meanings of the values stated in the “User Level” column:
0: Basic, Standard, and High function configuration
1: Standard and High function configuration
2: High function configuration
The initial value may vary depending on the model No.

Mode bank
Bank selection:
Display Item Contents
Initial
value
User
level
Notes
AUTO/MANUAL
mode selection
AUtO
: AUTO mode
MAn
: MANUAL mode
AUTO 0 Displayed when the control
method is other than the ON/
OFF control (
CtrL
≠0).
Whether or not this item is
displayed is selected by the
display mode setup (
C73
).
RUN/READY mode
selection
rUn
: RUN mode
rdy
: READY mode
RUN 0 Whether or not this item is
displayed is selected by the
display mode setup (
C73
).
LSP/RSP mode
selection
LSP
: LSP mode
rSP
: RSP mode
LSP 0 When the model provides
the RSP input, the display is
possible.
Whether or not this item is
displayed is selected by the
display mode setup (
C73
).
AT stop/start
selection
At.OF
: AT stop
At.On
: AT start
AT
stop
0 Displayed when the control
method is other than the ON/
OFF control (
CtrL
≠0).
Whether or not this item is
displayed is selected by the
display mode setup (
C73
).
Release all DO
latches
Lt.On
: Latch continue
Lt.OF
: Latch release
Latch
con-
tinue
0 All DO latches such as control
outputs (relay and voltage
pulse) and event outputs can
be released.
Whether or not this item is
displayed is selected by the
display mode setup (
C73
).
Communication DI1
dI.OF
: OFF
dI.On
: ON
OFF 0 Whether or not this item is
displayed is selected by the
display mode setup (
C73
).
