Azbil C35 Series User Manual

6-2
Chapter 6. LIST OF DISPLAYS AND SETTING DATA
Display Item Contents
Initial
value
User
level
Notes
Timer remaining
time 1
Setting is disabled.
Upper display: Displays the
distinction between ON delay and
OFF delay next to “
t1.
”.
Lower display: Displays in the unit
(any of 0.1 s, s, and min), which is
determined according to the delay
time unit of internal event 1 (3rd
digit of
E1.C3
).
— 0 Whether or not this item is
displayed is selected by the
event remain time display
setup (
C77
).
“
L
” is displayed at the right
end digit when using the ON
delay time.
“
L
” is displayed at the right
end digit when using the OFF
delay time.
Internal Event 2
main setting
The allowable setting range may
vary depending on the operation
type of the internal event.
-1999 to +9999 U: Set value is other
than the following values:
0 to 9999 U: Set value is an absolute
value.
-199.9 to +999.9 %: Set value is MV.
0 0 Setting required by the
operation type of the internal
event is displayed.
Whether or not this item is
displayed is selected by the
Event setting value display
setup (
C76
).
Internal Event 2
sub-setting
0 0
Timer remaining
time 2
Setting is disabled.
Upper display: Displays the
distinction between ON delay and
OFF delay next to “
t2.
”.
Lower display: Displays in the unit
(any of 0.1 s, s, and min), which is
determined according to the delay
time unit of internal event 2 (3rd
digit of
E2.C3
).
— 0 Whether or not this item is
displayed is selected by the
event remain time display
setup (
C77
).
“
L
” is displayed at the right
end digit when using the ON
delay time.
“
L
” is displayed at the right
end digit when using the OFF
delay time.
Internal Event 3
main setting
The allowable setting range may
vary depending on the operation
type of the internal event.
-1999 to +9999 U: Set value is other
than the following values.
0 to 9999 U: Set value is an absolute
value.
-199.9 to +999.9 %: Set value is MV.
0 0 Setting required by the
operation type of the internal
event is displayed.
Whether or not this item is
displayed is selected by the
Event setting value display
setup (
C76
).
Internal Event 3
sub-setting
0 0
Timer remaining
time 3
Setting is disabled.
Upper display: Displays the
distinction between ON delay and
OFF delay next to “
t3.
”.
Lower display: Displays in the unit
(any of 0.1 s, s, and min), which is
determined according to the delay
time unit of internal event 3 (3rd
digit of
E3.C3
).
— 0 Whether or not this item is
displayed is selected by the
event remain time display
setup (
C77
).
“
L
” is displayed at the right
end digit when using the ON
delay time.
“
L
” is displayed at the right
end digit when using the OFF
delay time.
