D-6
List of operation displays
Display
Upper display: PV
Lower display: SP
Item Contents Initial
value
Setting
value
PV
SP
SP (Target value) SP low limit to SP high limit 0
LSP
1
(
Display example
)
LSP
LSP No.
(
1st digit: Value at the right end digit
)
1 to LSP system group (Max. 8) 1
St
1-
(Display example)
Step No.
Step remaining time
Step operation remaining time Setting is disabled.
The step No. distinguishes up ramp, down ramp,
and soak.
PV
MV
MV (Manipulated Variable) -10.0 to +110.0% Setting is enabled in MANUAL
mode (Numeric value flashed)
HEAt
Numeric value
Heat MV (Manipulated Variable) Setting is disabled.
-10.0 to +110.0%
COOL
Numeric value
Cool MV (Manipulated Variable)
fb
Numeric value
MFB (Motor opening feedback
value)
Setting is disabled. +10.0 to +110.0%
Flashing when the value is 0.0 to 100.0% during estimate.
PV
At
1
(
Display example
)
AT progress display (1st digit=
Numeric value at right end digit)
Setting is disabled.
Ct
1
Numeric value
CT current value 1 Setting is disabled.
Ct2
Numeric value
CT current value 2 Setting is disabled.
E
1
Numeric value
Internal Event 1 main setting -1999 to +9999U or 0 to 9999U 0
E
1.Sb
Numeric value
Internal Event 1 sub setting 0
t
1.--
(
Display example
)
Numeric value
Timer remaining time 1 Setting is disabled.
Upper display: The distinction by ON delay or
OFF delay is displayed at the side location of “t1.”.
E2
Numeric value
Internal Event 2 main setting Same as Internal Event 1 main setting 0
E2.Sb
Numeric value
Internal Event 2 sub setting Same as Internal Event 1 sub setting 0
t2.--
(
Display example
)
Numeric value
Timer remaining time 2 Same as Timer remaining time 1
E3
Numeric value
Internal Event 3 main setting Same as Internal Event 1 main setting 0
E3.Sb
Numeric value
Internal Event 3 sub setting Same as Internal Event 1 sub setting 0
t3.--
(
Display example
)
Numeric value
Timer remaining time 3 Same as Timer remaining time 1
List of parameter setting displays
MOdE
[Mode bank]
Display Item Contents
Initial value
Setting value
A--M
AUTO/MANUAL
AUTO
: AUTO mode
MAN
: MANUAL mode
AUTO
r--r
RUN/READY
RUN
: RUN mode
RDY
: READY mode
RUN
l--r
LSP/RSP
lSp
: LSP
RSp
: RSP
LSP
At
AT stop/start
At.OF
: AT stop
At.ON
: AT start
AT stop
dO.Lt
Release all DO latches
Lt.ON
: Latch continue
Lt.OF
: Latch release
Latch continue
C.dI
1
Communication DI1
dI
.OF
: OFF
dI
.On
: ON
OFF
SP
[SP bank]
Display Item Contents
Initial value
Setting value
RSP
RSP Setting is disabled. –
PIDr
PID group No. (RSP) 1 to 8 1
SP-
1
to
SP-8
SP (for LSP 1 to 8) SP low limit to SP high limit 0
Pid.
1
to
Pid.8
PID group No. (for LSP 1 to 8) 1 to 8 1
rMP.
1
to
rMP.8
Ramp (for LSP1 to 8) 0 to 9999 0
tIM.
1
to
tI
M.8
Time (for LSP to 8) 0.0 to 999.9 or 0 to 9999 0
Ev
[Event bank]
Display Item Contents
Initial value
Setting value
E
1
to
E8
Internal Event 1 to 8 main setting
-1999 to +9999 or 0 to 9999 * 0
E
1.Sb
to
E8.Sb
Internal Event 1 to 8 sub setting
0
E
1.Hy
to
E8.Hy
Internal Event 1 to 8 hysteresis
0 to 9999 * 5
E
1.On
to
E8.On
Internal Event 1 to 8 ON delay time
0.0 to 999.9 or 0 to 9999 0
E
1.OF
to
E8.OF
Internal Event 1 to 8 OFF delay time
0
* The decimal point position varies by meeting the internal event operation type.
PI
D
[PID bank]
Display Item Contents
Initial value
Setting value
P-
1
to
P-8
Proportional band (PID1 to 8 group)
0.1 to 999.9% 5.0
I
-
1
to
I
-8
Integration time (PID1 to 8 group)
0 to 9999s or 0.0 to 999.9s
(No integration control action when set at "0")
120
d-
1
to
d-8
Derivative time (PID1 to 8 group) 0 to 9999s or 0.0 to 999.9s
(No derivative control action when set at "0")
30
rE-
1
to
rE-8
Manual reset (PID1 to 8 group) -10.0 to +110.0% 50.0
OL-
1
to
OL-8
MV low limit (PID1 to 8 group) -10.0 to +110.0% 0.0
OH-
1
to
OH-8
MV high limit (PID1 to 8 group) -10.0 to +110.0% 100.0
P-
1C
to
P-8C
Cool-side proportional band
(PID1 to 8 group)
0.1 to 999.9% 5.0
I
-
1C
to
I
-8C
Cool-side Integration time (PID1
to 8 group)
0 to 9999s or 0.0 to 999.9s
(No integration control action when set at "0")
120
d-
1C
to
d-8C
Cool-side derivative time (PID1
to 8 group)
0 to 9999s or 0.0 to 999.9s
(No derivative control action when set at "0")
30
OL.
1C
to
OL.8C
Cool-side MV low limit (PID1 to 8 group
)
-10.0 to +110.0% 0.0
OH.
1C
to
OH.8C
Cool-side MV high limit (PID1 to 8 group)
-10.0 to +110.0% 100.0
PARA
[Parameter bank]
Display Item Contents
Initial value
Setting value
Control
CtrL
Control method 0: ON/OFF control 1: Fixed PID 0 or 1
At.
OL
MV low limit at AT -10.0 to +110.0% 0.0
At.
OH
MV high limit at AT -10.0 to +110.0% 100.0
dI
FF
ON/OFF control differential 0 to 9999U 5
OFFS
ON/OFF control operating point offset
-1999 to +9999U 0
PV
FL
PV filter 0.0 to 120.0s 0.0
rA
PV ratio 0.001 to 9.999 1.000
bI
PV bias -1999 to +9999U 0
fl2
RSP filter 0.0 to 120.0s 0.0
ra2
RSP ratio 0.001 to 9.999 1.000
bI2
RSP bias -1999 to +9999U 0
Time proportional output
CyU
Time proportional cycle unit 1 0 to 3 *
1
0
Cy
Time proportional cycle 1 5 to 120s or 1 to 120s *
2
10 or 2
CyU2
Time proportional cycle unit 2 0 to 3 *
1
0
Cy2
Time proportional cycle 2 5 to 120s or 1 to 120s *
2
10 or 2
tP.
ty
Time proportional cycle mode
0: Controllability aiming type
1:
Operation end service life aiming type (Only ON/
OFF operation within Time proportional cycle)
0 or 1
MV
outl
MV variation limit 0.0 to 999.9%(No limit when set at "0.0U") 0.0
SP
SPU
SP up ramp (U/min) 0.0 to 999.9U(No ramp when set at "0.0U") 0.0
SPd
SP down ramp (U/min) 0.0
*1 0: Unit of "1s" 1: Fixed at 0.5s 2: Fixed at 0.2s 3: Fixed at 0.1s
*2 5 to 120s when output includes the relay output
U: Unit Maximum unit of Industrial volume in
PV range (°C, Pa,L/min, etc.)
: Essential parameters for PV measurement and control
: Basic parameters
: Required parameters when using optional functions
Et
[Extended tuning bank]
Display Item Contents
Initial value
Setting value
At.ty
AT type 0: Normal 1: Immediate response 2: Stable *
1
0
JF.bd
Just-FiTTER setting band 0.00 to 10.00 0.30
SP.LG
SP lag constant 0.0 to 999.9 0.0
At-P
AT Proportional Band adjust 0.00 to 99.99 1.00
At-I
AT Integral time adjust 0.00 to 99.99 1.00
At-d
AT Derivative time adjust 0.00 to 99.99 1.00
Ctr.A
Control algorithm
0: PID(Conventional PID) 1: Ra-PID(High-performance PID)
0
JF.Ov
Just-FiTTER assistance coefficient
0 to 100 0
*1 Normal = Standard control characteristics, Immediate response = Control characteristics that respond immediately to
external disturbance, Stable = Control characteristics having less up/down fluctuation of PV
ZOne
[Zone bank]
Display Item Contents
Initial value
Setting value
ZO-
1
to
ZO-7
Zone 1 to 7 -1999 to +9999U 9999U
ZOdf
Zone hysteresis 0 to 9999 5U 5U
List of setup setting displays
StUP
[Setup bank]
Display Item Contents
Initial value
Setting value
Analog input
C0
1
PV input range type For details, refer to the PV Input Range Table 88
C02
Temperature unit 0: Celsius (°C) 1: Fahrenheit (°F) 0
C03
Cold junction compensation
0: Performed (internal) 1: Not performed (external)
0
C04
Decimal point position 0: No decimal point
1 to 3: 1 to 3 digits below decimal point
0
C05
PV range low limit
When the PV input type is DC voltage/DC current,
-1999 to +9999U
0
C06
PV range high limit 1000
C07
SP low limit PV input range low limit to PV input range high
limit
0
C08
SP high limit 1000
C09
PV square root extraction dropout
0.0 to 100.0% (PV square root extraction is not
performed when set at "0.0".)
0.0
C
10
RSP input range type 0: 4 to 20mA 1: 0 to 20mA 2: 0 to 5V
3: 1 to 5V 4: 0 to 10V
0
C
1
1
RSP range low limit -1999 to +9999U 0
C
12
RSP range high limit 1000
Control action
C
13
PID calculation adjustment function
*
1
0: Enabled 1: Disabled 0
C
14
Control action (Direct/Reverse)
0: Heat control (Reverse action) 1: Cool control (Direct action)
0
C
15
Output operation at PV alarm 0: Control calculation is continued.
1: Output at PV alarm is output.
0
C
16
Output at PV alarm -10.0 to +110.0% 0.0
C
17
Output at READY (Heat) -10.0 to +110.0% 0.0
C
18
Output at READY (Cool) -10.0 to +110.0% 0.0
C
19
Output operation at changing AUTO/MANUAL
0: Bumpless transfer 1: Preset 0
C20
Preset MANUAL value -10.0 to +110.0%
0.0 or 50.0
C2
1
Initial output type (mode) of PID control
0: Auto 1: Not initialized 2: Initialized 0
C22
Initial output of PID control -10.0 to +110.0%
0.0 or 50.0
C23
PID decimal point position
(decimal
point of integral time and delivative time)
0: No decimal point
1: 1 digit after decimal point
0
C24
Zone PID operation 0: Disabled 1: Changed by SP 2: Changed by PV 0
C26
Heat/Cool control 0: Not used 1: Used 0
C27
Heat/Cool 0: Normal 1: Energy saving 0
C28
Heat/Cool control dead zone -100.0 to +100.0% 0.0
C29
Heat/Cool change point -10.0 to +110.0% 50.0
SP
C30
LSP system group 1 to 8 1
C3
1
SP ramp type 0: Standard 1: Multi-ram
2: Step operation When the power is turned ON
again, the step operation is stopped (READY)
3: Step operation When the power is turned ON
again, the step operation is reset
0
C32
SP ramp unit 0: 0.1U/s 1: 0.1U/min 2: 0.1U/h 1
C33
STEP time unit 0: 0.1s 1: 1s 2: 1min 0
C34
STEP PV start 0: Disabled 1: Enabled 0
C35
STEP loop 0: Stop 1: Loop 2: Final step continued 0
C36
CT1 operation type
0: Heater burnout detection 1: Current value measurement
0
C37
CT1 output
0 to 1: Control output 1 to 2, 2 to 4: Event output 1 to 3
0
C38
CT1 measurement wait time 30 to 300ms 30
C39
CT2 operation type Same as CT1 0
C40
CT2 output Same as CT1 0
C4
1
CT2 measurement wait time Same as CT1 30
Continuous output
C42
Control output 1 range
Current output 1: 4 to 20mA 2: 0 to 20mA
Continuous voltage output 1: 1 to 5 V 2: 0 to 5 V 3: 0 to 10 V
1
C43
Control output 1 type 0: MV 1: Heat MV 2: Cool MV 3: PV
4:
PV before ratio, bias, and filter
5: SP 6: Deviation
7:
CT1 current value
8:
CT2 current value
9:
MFB (Including estimation MFB)
10:
SP+MV
11:
PV+MV
0
C44
Control output 1 scaling low limit
-1999 to +9999U 0.0
C45
Control output 1 scaling high limit
100.0
C46
Control output 1 MV scalable bandwidth
0 to 9999 (Valid when control output 1 type is 10 or 11)
200
C47
Control output 2 range Same as control output 1 1
C48
Control output 2 type Same as control output 1 3
C49
Control output 2 scaling low limit
Same as control output 1 0
C50
Control output 2 scaling high limit
Same as control output 1 1000
C5
1
Control output 2 MV scalable bandwidth
Same as control output 1 200
C52
Auxiliary output range Same as control output 1 1
C53
Auxiliary output type Same as control output 1 3
C54
Auxiliary output scaling low limit
Same as control output 1 0
C55
Auxiliary output scaling high limit
Same as control output 1 1000
C56
Auxiliary output MV scalable bandwidth
Same as control output 1 200
Position proportional
C57
Position proportional type 0: MFB control + Estimated position control
1: MFB control
2: Estimated position control (MFB disabled)
3: Estimated position control (MFB disabled)
+ Position adjustment at power ON.
0
C58
Position proportional dead zone
0.5 to 25.0% 10.0
C59
Motor long life mode 0: Aiming at controllability
1: Aiming at service life of potentiometer
1
C60
Motor adjust 0: Stop 1: Start 0
C6
1
Input with motor fully closed 0 to 9999 1000
C62
Input with motor fully open 0 to 9999 3000
C63
Motor full close-full open time
5.0 to 240.0s 30.0
Communication
C64
Communication type
0: CPL 1: Modbus (ASCII format) 2: Modbus (RTU format)
0
C65
Station address
0 to 127 (Communication is disabled when set at "0".)
0
C66
Transmission speed (bps) 0: 4800 1: 9600 2: 19200 3: 38400 2
C67
Data format (Data length) 0: 7 bits 1: 8 bits 1
C68
Data format (Parity) 0: Even parity 1: Odd parity 2: No parity 0
C69
Data format (Stop bit) 0: 1 bit 1: 2 bits 0
C70
Communication minimum response time
1 to 250ms 3
Key operation • display
C7
1
Key operation type 0: Standard type 1: Special type 0
C72
[mode] key function 0: Invalid 1: AUTO/MANUAL selection
2: RUN/READY selection 3: AT Stop/Start
4: LSP group selection 5: Release all DO latches
6: LSP/RSP selection
7: Communication DI1 selection 8: Invalid
1
C73
MODE display setup
(Sum of the weighting)
Bit 0: AUTO/MANUAL display (Enabled: +1)
Bit 1: RUN/READY display (Enabled: +2)
Bit 2: LSP/RSP display (Enabled: +4)
Bit 3: AT Stop/Start display (Enabled: +8)
Bit 4:
Release all DO latches display (Enabled: +16)
Bit 5:
Communication DI1 ON/OFF display (Enabled: +32)
Other invalid setting, 0, +64, +128
255
C74
PV/SP display setup
(Sum of the weighting)
Bit 0: PV display (Enabled: +1)
Bit 1: SP display (Enabled: +2)
Bit 2: LSP group number display (Enabled: +4)
Other invalid setting, 0, +8
15
List of parameters
To Next Page
Loading...
Need help?
General
