Azbil C35 Series User Manual

6-12
Chapter 6. LIST OF DISPLAYS AND SETTING DATA
6 - 3 List of Setup Setting Displays
The following shows the meanings of the values stated in the “User Level” column:
0: Basic, Standard, and High function configuration
1: Standard and High function configuration
2: High function configuration
Initial value may differ depending on model No.

Setup bank
Bank selection:
Display Item Contents
Initial
value
User
level
Notes
PV input range type
Range of thermocouple: 1 to 26
Range of RTD: 41 to 68
Range of DC voltage and DC
current: 81 to 84, 86 to 90
88 0 For details, refer to the PV
Input Range Table (on page
5-2).
Temperature unit
0: Celsius (°C)
1: Fahrenheit (°F)
0 0 Displayed when the PV input range
type is thermocouple or RTD.
Cold junction
compensation (T/C)
0: Cold junction compensation (T/C)
is performed (internal).
1: Cold junction compensation (T/C)
is not performed (external).
0 2 Displayed when the PV input
range type is thermocouple.
Decimal point
position
0: No decimal point
1: 1 digit after decimal point
2: 2 digits after decimal point
3: 3 digits after decimal point
(Range with decimal point of
thermocouple/RTD: 0 to 1)
0 0 Displayed when the PV input
type is DC voltage/DC current
or thermocouple/RTD having
the range with the decimal
point.
PV range low limit
When the PV input range type is
thermocouple or RTD, the input
range low limit selected with the PV
input range type (
C0 1
) is displayed,
but the setting is disabled.
When the PV input range type is DC
voltage/DC current, a value ranging
from –1999 to +9999 is set.
0 0
PV range high limit
When the PV input range type is
thermocouple or RTD, the input
range high limit selected with the PV
input range type (
C0
1
) is displayed,
but the setting is disabled.
When the PV input type is DC
voltage/DC current, a value ranging
from –1999 to +9999 is set.
1000 0
SP low limit
PV range low limit to PV range high
limit
0 1
SP high limit 1000 1
PV square root
extraction dropout
0.0 to 100.0
(PV square root extraction is not
performed when set at “0.0”.)
0.0 2 Displayed when the PV input
range type is DC voltage/DC
current.
RSP input range type 0: 4 to 20 mA
1: 0 to 20 mA
2: 0 to 5 V
3: 1 to 5 V
4: 0 to 10 V
0 0 Displayed when the model
provides the RSP input.
RSP range low limit -1999 to +9999 U 0 0
RSP range high limit -1999 to +9999 U 1000 0
PID calculation
adjustment function
0: Enabled
1: Disabled
0 2 Normally, the PV filter is used
with an initial value.
If ROM version 1 in the
instrument information bank
(
i

d02
) is 2.26 or earlier, this
item cannot be displayed.
Control action
(Direct/Reverse)
0: Reverse action (Heat)
1: Direct action (Cool)
0 0 Displayed when the heat/cool
control is not used (
C26
=0).
