Chapter 8. Modbus COMMUNICATION FUNCTION
8 - 3 Description of Commands

Read command (03H)

Send Message
This is a command capable of reading the contents of continuous data addresses
from a specified read start data address with a single message. The following is an
example of send message while reading data:
Modbus ASCII
(2)(1) (3) (4)
3AH
:
30H
0
41H
A
30H
0
33H
3
30H
0
33H
3
45H
E
39H
9
30H
0
30H
0
30H
0
32H
2
30H
0
35H
5
0DH
CR
0AH
LF
(5) (6) (7)
(1) Start of message
(2) Station address
(3) Read command
(4) Start data address
(5) Number of read data
(6) Checksum (LRC)
(7) Delimiter
Modbus RTU
(2)(1) (3) (4)
0AH 03H 03H E9H 00H 02H 14H
(5)
C0H
(1) Station address
(2) Read command
(3) Start data address
(4) Number of read data
(5) Checksum (CRC)

Response Message
A response message corresponding to the command content is returned when the
message is correctly received.
The figure below shows the structure of the response message while reading data.
Modbus ASCII
• Example in case of normal reception
(2)(1) (3) (4)
3AH
:
30H
0
41H
A
30H
0
33H
3
30H
0
34H
4
30H
0
33H
3
30H
0
31H
1
30H
0
30H
0
30H
0
33H
3
45H
E
38H
8
D0H
CR
0AH
LF
(5) (6) (7) (8)
(1) Start of message
(2) Station address
(3) Read command
(4) Number of read data X 2
(5) Read data 1
(6) Read data 2
(7) Checksum (LRC)
(8) Delimiter
