5-1
Chapter 5. DETAILED DESCRIPTION OF EACH
FUNCTION
5 - 1 PV Input
The following shows the functional block diagram of the PV input:
PV input is thermocouple.
PV input range type
(Setting: Setup C0 1)
Cold junction compensation
(Setting: Setup C03)
Temperature unit
(Setting: Setup C02)
PV input range type
(Setting: Setup C0 1)
Temperature unit
(Setting: Setup C02)
PV high limit/low limit alarm
PV ratio (Setting: Parameter rA)
PV bias (Setting: Parameter bI )
PV lter (Setting: Parameter FL)
PV high limit/low limit
PV hold
(Setting: DI Assignment Operation type dI 1. 1 to dI 5. 1)
PV before ratio, bias, and lter
PV
PV input is DC voltage/DC current.
PV input range type
(Setting: Setup C0 1)
PV square root extraction
(Setting: Setup C09)
Decimal point position and scaling
(Setting: Setup C04 to C06)
To Next Page
