5-2
Chapter 5. DETAILED DESCRIPTION OF EACH FUNCTION
PV input range type
When the PV input range type is thermocouple or RTD, the sensor type and
temperature range can be selected. When the PV input range type is DC voltage or
DC current, the signal type can be selected.
Item (Bank) Display Contents Initial value User level
PV input range type
(Setup bank)
Refer to the PV input range table. 88 Basic,
Standard,
High function
PV input range table (Thermocouple)
C0
1
set value
Sensor type Range
(Celsius)
Range
(Fahrenheit)
C04
display
C04
range*
3
C04
initial value when
C0
1
settings*
4
1 K –200 to +1200°C –300 to + 2200˚F ---- Not setting No decimal point
2 K 0 to 1200°C 0 to 2200˚F ---- Not setting No decimal point
3 K 0.0 to 800.0°C 0 to 1500˚F
0 to 1 0
4 K 0.0 to 600.0°C 0 to 1100˚F
0 to 1 1
5 K 0.0 to 400.0°C 0 to 700˚F
0 to 1 1
6 K –200.0 to +400.0°C –300 to +700˚F
0 to 1 1
7 K –200.0 to +200.0°C –300 to +400˚F
0 to 1 1
8 J 0 to 1200°C 0 to 2200˚F ---- Not setting No decimal point
9 J 0.0 to 800.0°C 0 to 1500˚F
0 to 1 1
10 J 0.0 to 600.0°C 0 to 1100˚F
0 to 1 1
11 J –200.0 to +400.0°C –300 to +700˚F
0 to 1 1
12 E 0.0 to 800.0°C 0 to 1500˚F
0 to 1 1
13 E 0.0 to 600.0°C 0 to 1100˚F
0 to 1 1
14 T –200.0 to +400.0°C –300 to +700˚F
0 to 1 1
15 R 0 to 1600°C 0 to 3000˚F ---- Not setting No decimal point
16 S 0 to 1600°C 0 to 3000˚F ---- Not setting No decimal point
17 B 0 to 1800°C 0 to 3300˚F ---- Not setting No decimal point
18 N 0 to 1300°C 0 to 2300˚F ---- Not setting No decimal point
19 PL II 0 to 1300°C 0 to 2300˚F ---- Not setting No decimal point
20 WRe5-26 0 to 1400°C 0 to 2400˚F ---- Not setting No decimal point
21 WRe5-26 0 to 2300°C 0 to 4200˚F ---- Not setting No decimal point
22 Ni-NiMo 0 to 1300°C 0 to 2300˚F ---- Not setting No decimal point
23 PR40-20 0 to 1900°C 0 to 3400˚F ---- Not setting No decimal point
24 DIN U –200.0 to +400.0°C –300 to +700˚F
0 to 1 1
25 DIN L –100.0 to +800.0°C –150 to +1500˚F
0 to 1 1
26 Gold iron chromel 0.0 K to 360.0 K 0.0 K to 360.0 K
0 to 1 1
*1. The accuracy varies according to the range.
The accuracy of the B thermocouple is ±4.0%FS for a range of 260°C or less, ±0.4%FS for 260 to 800°C and ±0.2%FS
for 800 to 1800°C. The PV values under 20°C are not shown.
The accuracy of the No. 15 (sensor type R) or No. 16 (sensor type S) is ±0.2%FS for a range of 100°C or less, and
±0.15%FS for 100 to 1600°C.
The accuracy of the No. 23 (sensor type PR40-20) is ±2.5%FS for 0 to 300°C, and ±1.5%FS for 300 to 800°C, ±0.5%FS
for 800 to 1900°C.
The accuracy of the No. 26 (sensor type gold iron chromel) is ±1.5K.
The accuracy of the No. 55 to 62 and 81 are ±0.15%FS for each ranges.
The accuracy of the No. 19 (sensor type PLII) in the range of 0 to 32˚F does not meet the indication accuracy.
*2. The indicated low limit for a B thermocouple is 20°C. However, if ROM version 1 of the instrument information bank
(
I
d02
) is prior to 2.04, the value is -180°C.
*3. "Not setting" fixed when Fahrenheit settings.
*4. "No decimal point" fixed when Fahrenheit settings.
