5-3
Chapter 5. DETAILED DESCRIPTION OF EACH FUNCTION
PV input range table (RTD)
C0
1
set value
Sensor type Range
(Celsius)
Range
(Fahrenheit)
C04
display
C04
range
C04
initial value when
C0
1
settings
41 Pt100 –200.0 to +500.0°C –300 to +900˚F
0 to 1 1
42 JPt100 –200.0 to +500.0°C –300 to +900˚F
0 to 1 1
43 Pt100 –200.0 to +200.0°C –300 to +400˚F
0 to 1 1
44 JPt100 –200.0 to +200.0°C –300 to +400˚F
0 to 1 1
45 Pt100 –100.0 to +300.0°C –150 to +500˚F
0 to 1 1
46 JPt100 –100.0 to +300.0°C –150 to +500˚F
0 to 1 1
47 Pt100 –100.0 to +200.0°C –150 to +400˚F
0 to 1 1
48 JPt100 –100.0 to +200.0°C –150 to +400˚F
0 to 1 1
49 Pt100 –100.0 to +150.0°C –150 to +300˚F
0 to 1 1
50 JPt100 –100.0 to +150.0°C –150 to +300˚F
0 to 1 1
51 Pt100 –50.0 to +200.0°C –50 to +400˚F
0 to 1 1
52 JPt100 –50.0 to +200.0°C –50 to +400˚F
0 to 1 1
53 Pt100 –50.0 to +100.0°C –50 to +200˚F
0 to 1 1
54 JPt100 –50.0 to +100.0°C –50 to +200˚F
0 to 1 1
55 Pt100 –60.0 to +40.0°C –60 to +100˚F
0 to 1 1
56 JPt100 –60.0 to +40.0°C –60 to +100˚F
0 to 1 1
57 Pt100 –40.0 to +60.0°C –40 to +140˚F
0 to 1 1
58 JPt100 –40.0 to +60.0°C –40 to +140˚F
0 to 1 1
59 Pt100 –10.00 to +60.00°C –10 to +140˚F
0 to 2 2
60 JPt100 –10.00 to +60.00°C –10 to +140˚F
0 to 2 2
61 Pt100 0.0 to 100.0°C 0 to 200˚F
0 to 1 1
62 JPt100 0.0 to 100.0°C 0 to 200˚F
0 to 1 1
63 Pt100 0.0 to 200.0°C 0 to 400˚F
0 to 1 1
64 JPt100 0.0 to 200.0°C 0 to 400˚F
0 to 1 1
65 Pt100 0.0 to 300.0°C 0 to 500˚F
0 to 1 1
66 JPt100 0.0 to 300.0°C 0 to 500˚F
0 to 1 1
67 Pt100 0.0 to 500.0°C 0 to 900˚F
0 to 1 1
68 JPt100 0.0 to 500.0°C 0 to 900˚F
0 to 1 1
PV input range table (DC voltage/DC current)
C0
1
set value
Sensor type Range
C04
display
C04
range
C04
initial value
when
C0
1
settings
81 0 to 10 mV
• Scaling range is -1999 to +9999.
• When
C0
1
is changed, the range
defaults to 0 to 1000.
0 to 3 No change
82 –10 to +10 mV
0 to 3 No change
83 0 to 100 mV
0 to 3 No change
84 0 to 1 V
0 to 3 No change
86 1 to 5 V
0 to 3 No change
87 0 to 5 V
0 to 3 No change
88 0 to 10 V
0 to 3 No change
89 0 to 20 mA
0 to 3 No change
90 4 to 20 mA
0 to 3 No change
Handling Precautions
• When the
C0
1
PV input range number is set, the decimal point position and
range are initially set automatically as shown in the tables. For details on the
decimal point, refer to the description of setup
C04
(decimal point position)
on page 5-5.
• Make sure to set the correct number in setup display
C0
1
, according to the
type and range of the sensor used. If the setting is wrong, problems such as
large temperature errors in the output may occur.
• For details about the accuracy of each PV input range type,
Chapter 13. SPECIFICATIONS (p.13-1).
