BALTECH VP-3470
Operation manual
Technical description 15
4. Technical description
4.1. Application
The vibrometer-balancer BALTECH VP-3470 is designed to perform:
1) measuring, recording and analysis of the vibration parameters, rotation frequency
of rotating machines and mechanical structures with the purpose of monitoring and
diagnostics of their technical condition. BALTECH VP-3470 allows performing the on-
site monitoring of electric motors, pumps, fans, exhausters, compressors, turbines,
generators in various industries.
2) balancing (up to 4 correction planes and 16 measure points).
4.2. Technical characteristics
The technical characteristics of BALTECH VP-3470 are given in the Table below.
Table 2. Technical characteristics
Frequency range, Hz from 2 to 10000
Measurement range of RMS vibration
acceleration at the base frequency
159.2 Hz, m/s²
from 0,5 to 300
Measurement range of RMS vibration
velocity at the base frequency 159.2
Hz, mm/s
from 0,5 to 200
Measurement range of vibration
displacement Peak-Peak at the base
frequency 79,6 Hz, um
from 1 to 1000
Permissible absolute error of RMS
vibration acceleration measurement
within the frequency range 10 – 5000
Hz within the operation range of
amplitude and temperature, m/s²
±(10%А + 0.1), where A –current
value of the vibration acceleration, m/
s²
Permissible absolute error of RMS
vibration velocity measurement within
the frequency range 10 – 2000 Hz
within the operation range of amplitude
and temperature, mm/s
±(10%V + 0.1), where V –current
value of the vibration velocity, mm/s
