62 Measurements
BALTECH VP-3470
Operation manual
When viewing the graph use the button 3 (decrease) and 4 (increase) to adjust
the scale.
Press 0 to perform the measurement again. To return to the settings press Cancel.
3. Press Enter to save the measurement results.
Figure 57. Report saving
8.8. Peak and phase
1. Set the function parameters and press Enter to start the measurement.
Figure 58. Peak and phase settings
