3. When installing the angle gauge following two conditions must be observed:
a) The front plane of the angle gauge must be perpendicular to the rotor rotation 
axis;
b) In any rotor position the indicator of the angle gauge must be always available 
for taking the readings.
4. Switch on the angle gauge by pressing the Power key. Use 0 to reset the readings.
5. The angle gauge shows angles in the range ± 180º. If the calculated angle is less
than 180 degrees, rotate the rotor against direction of rotation till the angle gauge
shows the result. The place of installation of the correction weight will be opposite
to the mark on the stationary part of the machine (p.2). 
6. If the calculated angle is more than 180 degrees, the rotor must be rotated
towards  direction  of  rotation  by  360°C-  Fnominal,  where  Fnominal  is  the  angle 
position value of the correction weight. The place of installation of the correction
weight is opposite to the mark on the stationary part of the machine (p.2). 
When using the digital angle gauge always observe the safety measures.
5.4. Power connection
BALTECH VP-3470 is powered from four LiFePO4 batteries that are installed in the
display unit. The batteries are charged from a standard network adapter 5V (Figure 
12). 
