Banner SC26-2 User Manual

Mute Bypass
BypassTime
Expired
BypassTime
Expired
On or Off
M0:OS1
M0:MSP1-1
M0:MSP1-2
M0:BP1
M0:SO1
Figure 27. Mute Bypass
Mute Function
One Way - 1 Sensor Pair
Max.
Time
Max.
Time
Max.
Time
Max.
Time
< 3s< 3s
Mute ends due to
defined area going clear
Mute ends due to
defined area going clear
Note: MO:OS1 must be blocked before either MSP1-1 or MSP1-2 clears.Note: MO:OS1 must be blocked before either MSP1-1 or MSP1-2 clears.
End Delay Timer
M0:SO1
M0:OS1
Mute
M0:ME1
M0:MSP1-1
M0:MSP1-2
< 3s< 3s
Mute ends due to
Mute Delay timeout
Mute ends due to
Mute Delay timeout
On or Off
On or Off
Figure 28. Timing Diagram—One-Way Muting Block, One Muting Sensor Pair
XS/SC26-2 Safety Controller
34
