Barco DP2K-32B - Introduction

6. Input & communication
6.1 Introdu ction
General
The input & com m unication side of a DP2K-32B projector consists of a button module and 3 separate removable u nits, fan controller
module, Integrated cinema processor (ICP), HDSDI module and a C inema c ontroller m odule.
1
2
3
4
5
6
A
B
C
G
D
F
E
Image 6-1
Input and communication
A
Local keypad (button module)
B
Communication ports
C
DVI input ports
D
Socket for security key
E Fan controller module
F
USB ports (for future ex pansion) and
LED indications for service purpo ses
G SMPTE inputs (HDSDI)
CAUTION: A unit m ay only be removed by qualified service personnel. Removing a u nit w ill result in an
authorization request upon starting.
64 R59770491 DP2K-32B 30/04/2010
