8. Installation menu
Top oset
Top height
Left oset
Left width
Right oset
Right width
Bottom height
Bottom oset
0
0
0
0
0
0
00
Enable Show lines
Image 8-9
How to ca librate the Blend Zone with pictures side by side.
Use the up/down/left/right arrow key on the remote control or key pad to navigate in the menu.
For B lend adjustment in side by side c onfiguration, the steps are as follows, starting with the left picture:
• By the ar row keys, place the display cursor on respectively the “Enable” z one and the “Show Lines” zone and a ctivate them by
pressing enter.
• Using the arrow keys, place the cursor on the “Right Width” zone, press enter.
• Adjust the width value by using the arrow keys up (or down), one step at a time. By pressing the k ey arrow c onstantly, the blend
value will increase rapidly. T he numeric value of the width is shown on t he screen next to the alignm ent line. The number
entered represen t the mov emen t exp ressed in n um ber of pixels.Confirm position by pressing enter.
• Exit the menu by using the ex it button on the remote control.
For the right p icture, repeat the procedure, but adjust the Left W idth instead of the right w idth.
When th e projectors a re correctly adjusted, the cursor lines shall be abo ve the outer frame of the opposite screen.
For B lend adjustments in over / under configuration, the proce dure is the same, b ut use the Top and Bottom height instead, and
perform a similar procedure .
Instead of adjusting the lines by the arrow keys, the value can also be typed directly using the numeric keys on the remote control.
To remove or undo the entered num bers, use the * key on the remote c ontrol.
The Offset adjustments.
The o ffset adjustments are used to cut the image on each side (Masking). Normally used to hide parts of the picture that shall not
be shown on the screen. An example can be : If the source is a pc, you may want to hide the menu bar at the bottom of the screen.
8.6 Illumination
About
Home/Installation /Illumination/Power
Review light source status and adjust (dim) laser power from 0 to 100% .See also "IR / Night vision functionality", page 49
Default: 100%
58
601–426 F70 SERIES 16/06/2017
