6. Source menu
6. SOURCE MENU
About the Source me nu
This menu is used to select, review and configure sour ces into the projector. Enables either via the s ource menu, or the sho rtcut k ey.
By navigate t hrough the Home/Source m enu, it will be visible also on the OSD .
By using the shortcut k ey, the menu occ urs only on the LCD disp lay.
Overview
• Connector selection
• Connector Settings
• Using Dual DV I or Dual Display Port
6.1 Connector selection
About
Source / {Source}
Click on the relevant input connector icon to swap or activate the sou rce.
The icon fo r the active source is highlighted.
The list of displayed s ources can be adjusted to include other connectors.
The default selection of connectors displayed is:
•DVI1
•DVI2
• Dual DVI
• Display Port 1
• Display Port 2
• Dual D isplay Port
• HDBaseT
• HDMI
•SDI
6.2 Connector Settings
About
Home/Source/ConnectorSettings
The Connector settings m enu allows to change settings for the DVI, Display Port, HDMI, HDBaseT and SDI inputs. Default value
are set to Auto. When entering the menu for each input, there are some selectable choices.
6.3 Using Du al DVI or Dual Display Port
Dual Head Input.
For extended flexibility to connect high res olution sour
ces with a pixel clock over 330 MHz, the projector is supporting a dual head
input mode. In this mode, the left and the right half of the im age can be connected to the DVI-I1 and DVI-I2 respectively, or DP1
and DP2.
To enable this mode, select the source menu Source — Dual DVI (or Dual D P).
It is important to s et up the signal s ource in dual mode with the correct resolution,
601–426 F70 SERIES 16/06/2017
47
