2. Parts, controls and connectors
2.4.8 S-Video and S-Video-out connector
Overview
Image 2-12
Pin Function
1
Ground (Y)
2
Ground (C)
3
Luminance (Y)
4
Chroma (C)
SG Shielded Ground
12 (451920611391)K5903031 MDSC-2224 21/01/2014
