5. Advanced operation
5.4.4 Extended keyboard
About the extended keyboard
The concept of the extended keyboard is to present a large selection of functions immediately available
to the user without the need to navigate through the OSD Menu.
Once enabled, by simply pressing one of the first 3 keys on the left the user is presented with a list of new
selections displayed on screen; the new choices can be selected by using each of the key just below the
OSD text.
If two options are available for one key, the first key press will select the upper option, a second press
selects the lower option.
The different available extended keyboard functions are:
• Main source selection
• Second source selection
•Multi-imageconfiguration
• Color temperature selection
• Image size selection
• Zoom factor selection
To enable/disable the extended keyboard
1. Bring up the OSD main menu.
2. Navigate to the Configuration menu.
3. Enter the Extended keyboard submenu.
4. Enable/Disable the extended keyboard as desired and confirm.
5.4.5 OSD setting
5.4.5.1 OSD Horizontal Position
To adjust the OSD horizontal position
1. Bring up the OSD main menu.
2. Navigate to the Configuration menu.
3. Enter the OSD setting submenu.
4. Select OSD Hor. Pos.
The command bar OSD Hor. Pos. is highlighted.
5. Set the OSD horizontal position as desired and confirm.
5.4.5.2 OSD Vertical Position
To adjust the OSD vertical position
1. Bring up the OSD main menu.
2. Navigate to the Configuration menu.
3. Enter the OSD setting submenu.
4. Select OSD Ver. Pos.
The command bar OSD V er. Pos. is highlighted.
5. Set the OSD vertical position as desired and confirm.
42
(451920611391)K5903031 MDSC-2224 21/01/2014
