5. Advanced operation
3. Enter the Zo om submenu.
4. Select one of the available zoom factors and confirm.
5.3.4 Image Size
About image size
The available image sizes for your display are:
• Full Screen (fill the screen, image aspect-ratio can be altered)
•Aspect(fill the screen on largest dimension, no modification in image aspect-ratio)
• Native (input pixel to LCD pixel mapping, no scaling)
In Aspect and Native, the image may be displayed with black bars on top/bottom or
left/right.
The image size can also be selected via the extended keyboard functionality.
To select the image size
1. Bring up the OSD main menu.
2. Navigate to the Display Format menu.
3. Enter the Image Size submenu.
4. Select one of the available image sizes and confirm.
5.3.5 2
nd
Picture Mode
About 2
nd
picture modes
Theavailable2
nd
picture modes for your display are:
•Off
• Small PiP: 30% of Primary height in top-right corner
• Large PiP: 50% of Primary height in top-right corner
• Side-by-Side: Primary and Secondary input of equal height
• S.b.S. Native: The 2 images are displayed with input pixel to LCD pixel mapping, with image crop if
necessary
• S.b.S. Fill: Both images scaled to fill half of the screen, with image crop if necessary
The 2
nd
picture mode (multi-image configuration) can also be selected via the extended
keyboard functionality.
To select the 2
nd
picture mode
1. Bring up the OSD main menu.
2. Navigate to the Display Format menu.
3. Enter the 2
nd
Picture Mode submenu.
4. Select one of the available 2
nd
picture modes and confirm.
38
(451920611391)K5903031 MDSC-2224 21/01/2014
