Page #25 background image
4. Daily operation
While pressing the stand-by key to switch off the display, the front key illumination will
blink.
4.4 Power led status
About the the power led status
The behavior of the power led shows the status of the unit:
No led visible: the status of the unit is hard OFF (the switch of the power supply is OFF)
Led is fading between on and off: the status of the unit is soft OFF (when pushing the standby button,
the unit is on or off)
Led is full orange: the unit is in power save mode (no signal & power save mode enabled)
Led is blinking green/orange: the unit is in searching mode (looking for a signal)
Led is full green: the unit has an image on the screen.
4.5 OSD menu activation
To activate the OSD menu
1. If not already done so, switch on the display by pressing and holding the stand-by key for approxi-
mately 3 seconds.
2. Switch on the front key illumination by activating the keyboard (see "Keyboard activation/deactivation",
page 21).
3. Touch the Menu/Enter key
.
As a result, the OSD main menu comes up in the bottom right corner of the screen. If no further actions
are taken within the following 30 seconds, the OSD menu will disappear again.
The time-out of the OSD me nu automatic close function can be adjusted or dis abled in
the OSD menu (OSD Time-out).
The OSD menu position can be adjusted in the OSD menu (OSD Hor. Pos.
and OSD Vert.
Pos.).
4.6 O SD menu navig ati on
OSD menu structure explained
Below is on example of how the OSD menu structure looks like:
(451920611391)K5903031 MDSC-2224 21/01/2014
23
