Barco MDSC-2224 User Manual

6. Important information
LED version: 65WPower consumption
MNA version: 85W
Power save mode Yes
Dot clock
165 MHz max. (DVI)
OSD languages English, French, German, Spanish, Italian
Display dimensions w/o stand
(WxHxD)
595,4 x 414 x 84 mm (23.44 x 16.3 x 3.31 in)
Power Supply dimensions (W
xHxD)
210 x 103 x 52 mm (8.27 x 4.06 x 2.05 in)
Dimensions packaged (W x H
xD)
685 x 570 x 170 mm (26.97 x 22.44 x 6.69 in)
Net weight display w/o stand 7.9 kg (17.4 lbs) (9.5 kg (20.9 lbs) incl. power supply and accessories)
Net weight power supply
1.5 kg (3.31 lbs)
Net weight packaged w/o
stand
12.0 kg (26.5 lbs)
Power supply DC output cable
length
2.5 m (8.2 ft)
Mounting standard
VESA (100 mm)
Screen protection Protective, non-reflective PMMA cover
Recommended modalities
Endoscopy, Laparoscopy, PACS, PM, US, CT, MR
Certifications ANSI/AAMI ES 60601-1, 3rd edition: 2005 EN 60601 3rd edition:
2006 IEC 60601-1, 3rd edition (2005) CE (MDD) Class I, essential
requirements of MDD 93/42/EEC, version 20
07(ineffectasofMarch
2010) CAN/CSA-C22.2 No 60601.1-08, IEC / EN 60601-1-2: 2007,
EN 55011 / CISPR11 (MDSC-2224-MNA: Class A; MDSC-2224 LED:
Class B), FCC (A or B depending on model), RoHs compliant, IP21
(IPx5 front side only)
User Guide
Video cable (DVI Dual Link)
Mains cables (European (CEBEC/KEMA), USA (UL/CSA))
Supplied accessories
External power supply
Optional accessories Barco stand (K9302032A)
Power extension cable 10m (K3495066)
Power extension cable 30m (K3495068)
Warranty 3 years
Operating temperature 10-35°C for performance / 0-40°C for safety
Storage temperature -20 ÷ +60°C
Operating humidity 10 ÷ 90% (non-condensing)
Storage humidity 10 ÷ 90% (non-condensing)
Operating altitude 3 000 m max.
Storage altitude 12000 m max.
Timings DVI-VGA
Item Name Pixel x Line Format Hor. Fr.
(kHz)
Vert. Fr.
(Hz)
Hor.
Total
Vert.
Total
DVI
VGA
1 480i 720 x 487
NTSC
15,734 59,94 Y N
2 480p59 720 x 480 480p 31,47 59,94 Y N
3 480p60 720 x 480 480p 31,5 60 Y N
4 576i 720 x 576 PAL I 15,625 50 Y N
5
576p 720 x 576 576p 31,25 50 Y N
56 (451920611391)K5903031 MDSC-2224 21/01/2014
