4. Lamp & Lamp House
4. LAMP & LAMP HOUSE
WARNING: DO NOT PER MIT UNAUTHORIZED PERSONNEL TO PERFORM OR ATTEMPT ANY PHASE OF
XENON LAM P HA NDLING OR SERVICE. ONLY TRAINED AND QUALIFIED TECHNICAL SERVICE PERSONNEL
ARE ALLOWED TO HANDLE THE XEN ON LAMP.
CAUTION: Xenon comp act arc lamps are highly p ressurized. When ignited, the normal operating temperature
of the bulb increases the pressure to a level at which the bulb m a y explode if not handled in strict accordan ce
to the manufacturer’s instructions. The bulb is stable at room temperature, but may still explode if dropped or
otherwise mishandled. W hen ever the lamp house, containing a xenon lamp , has to be dism antled or when ever
the protective container or cloth has to be removed from the xenon lamp , authorized protective clothing MU ST
be worn!
WARNING: Always wear face protection (full face shield w ith n eck p rotector) w hen handling xenon lamps.
WARNING: Alw ays wear protective clothing (welder ’s jacket) w hen handling x enon lamps.
WARNING: Alwa ys wear clean leather gloves w ith w rist p rotectors when handling xeno n lamps.
Overview
• Introduction
• Supported xenon lamps for the S/M Lamp House
• Removal of the L amp Hou se
• Removal of the xenon lamp from m anual S/M L amp House
• Installation of the xenon lamp in manu al S /M Lamp House
• Installation of the Lamp House
• Resetting the lamp parameters
• Realignment of the lamp in its reflector (manual Lamp H ou
se)
4.1 Introduction
Lamp a nd Lamp House
The DP xK-19B/23B/P projector is delivered with a manual or m otorized S/M L am p House without lamp. The xeno n bulb lamp is
delivered separately and has to be installed on site by a qualified service t echnician.
The xenon bulb lamp is packed in a protective container or wrapped in a protective cloth. Never remove this protective container or
protective cloth without w e aring adequate protective clothing (face shield, clean cotton gloves, welder’s jacket).
Image 4-1
Left: Xenon lamp in protective container. Right: Xenon lamp wrapped in protective cloth.
R5905067 DPXK-19B/23B/P 17/09/2012 27
