Barco RLM W6 User Manual

55
Signal
Type
Resolution
Frame
Rate
Video S-Video SCART (RGB-S) Y-Pr-Pb (YUV1) HD15, BNC - RGBHV HD15, BNC - YUV HDMI - RGB HDMI - YUV
References
PC
640×480 59.94 × × VESA DMT, CEA-861D Format 1
640×480 74.99 × × VESA DMT
640×480 85 × × VESA DMT
800×600 60.32 × × VESA DMT
800×600 75 × × VESA DMT
800×600 85.06 × × VESA DMT
848×480 47.95 × × VESA CVT
848×480 59.94 × × VESA CVT
1024×768 60 × × VESA DMT
1024×768 75.03 × × VESA DMT
1024×768 85.03 × × VESA DMT
1280×720 47.95 × × VESA GTF
1280×1024 60.02 × × VESA DMT
1280×1024 75.02 × × VESA DMT
1280×1024 85.02 × × VESA DMT
1400×1050 60 × × VESA CVT
1600×1200 60 × × VESA DMT
1920×1080 47.95 × × VESA CVT
1680×1050 59.94 × × VESA CVT
1920×1200 50.00 × x PCLK = 158.25MHz
1920×1200 RB 59.94 × × VESA CVT, PCLK=153.75MHz
1920×1200 RB 60 × × VESA CVT, PCLK=154MHz
Apple Mac
640×480 66.59 × × VESA DMT
832×624 74.54 × × VESA DMT
NTSC NTSC (M, 4.43) 59.94 × × ITU-R BT.1700, SMPTE 170M
PAL
PAL (B,G,H,I) 50 × × ITU-R BT.1700
PAL (N) 50 × × ITU-R BT.1700
PAL (M) 59.94 × × ITU-R BT.1700
SECAM SECAM (M) 50 × × ITU-R BT.1700
SDTV
RGBS 50 × RS-170, SCART, ITU-R BT.656
1440x480i 60 × × CEA-861-D Format 6 & 7
1440x576i 50 × × CEA-861-D Format 21 & 22
480i 59.94 × SMPTE 125M
576i 50 × ITU-R BT.601
EDTV
480p 59.94 × × × × × SMPTE 293M, CEA-861-D Format 2 & 3
576p 50 × × × × × ITU-R BT.1358, CEA-861-D Format 17 & 18
HDTV
1035i 60 x × × × × SMPTE 260M
1080i 50 × × × × × SMPTE 274M, CEA-861-D Format 20
1080i (Aus) 50 × × × × × SMPTE 295M
1080i 59.94 × × × × × SMPTE 274M, CEA-861-D Format 5
1080i 60 x × × × × SMPTE 274M, CEA-861-D Format 5
720p 50 × × × × × SMPTE 296M, CEA-861-D Format 19
720p 59.94 x × × × × SMPTE 296M, CEA-861-D Format 4,
720p 60 × × × × × SMPTE 296M, CEA-861-D Format 4
1080p 23.98 x × × × × SMPTE 274M, CEA-861-D Format 32
1080p 24 × × × × × SMPTE 274M, CEA-861-D Format 32
1080p 25 x × × × × SMPTE 274M, CEA-861-D Format 33
1080p 29.97 × × × × × SMPTE 274M, CEA-861-D Format 34
1080p 30 x × × × × SMPTE 274M, CEA-861-D Format 34
1080p 50 × × × × × SMPTE 274M, CEA-861-D Format 31
1080p 59.94 x × × × × SMPTE 274M, CEA-861-D Format 16
1080p 60 x × × × × SMPTE 274M, CEA-861-D Format 16
Projector specications
9

Barco RLM W6 Specifications

General

Matrix size	0.67 \
Heat dissipation	2900 BTU/h
Projection distance	- m
Projection technology	DLP
Contrast ratio (dynamic)	3000:1
Contrast ratio (typical)	2200:1
Digital gamma correction	Yes
Screen size compatibility	- \
Projector native resolution	WUXGA (1920x1200)
Aspect ratio	16:10
RS-232 ports	1
Dimensions (WxDxH)	516.7 x 669.74 x 247 mm
Maximum analog resolution	1600 x 1200 pixels
Maximum digital resolution	1920 x 1200 pixels
Focal length range	- mm
Vertical lens shift range	0 - 100 %
Horizontal lens shift range	-30 - 30 %
Lamp power	330 W
Lamps quantity	2 lamp(s)
Light source type	Lamp
Service life of light source	1500 h
Service life of light source (economic mode)	2000 h
Noise level	39 dB
Preset modes	sRGB, Standard
Certification	FCC, CE EN55022 Cl. A, CE, TUV, WEEE.
Dot clock scanning frequency	165 MHz
Full HD	No
Analog signal format system	NTSC
Supported graphics resolutions	1600 x 1200 (UXGA), 1920 x 1200 (WUXGA)
BNC input ports	5
Serial interface type	RS-232
USB 2.0 ports quantity	0
Ethernet LAN data rates	10, 100 Mbit/s
Placement	Desktop, Ceiling
Product type	Large venue projector
Product color	Black
Market positioning	Presentation
Power source	AC
AC input frequency	50 - 60 Hz
Power consumption (standby)	2 W
Power consumption (typical)	850 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 80 %
Cables included	AC, HDMI-DVI
Remote control type	IR
Sustainability certificates	RoHS

Weight and Dimensions

Depth	669.74 mm
Width	516.7 mm
Height	247 mm
Weight	26000 g
Package weight	30000 g
