5. Repeat from step 1 until the projected focus pattern is as sharp as possible in the center, left, right, top and
bottom of the screen.
6. Fasten all three lock screws again. Use a torque wrench with a torque of 8.4 Nm.
Tip: While a stronger torque can be applied, take into account that the maximum allowed torque
is 10 Nm.
What to do when no sharp image can be obtained?
If you are unable to obtain a sharp image, even after performing all previously mentioned lens adjustment
procedures, you may have messed up the Scheimpflug procedure. This can be fixed by adjusting the
adjustment points in such a way the lens holder is returned to its nominal position. In order to do so, consult
the service manual.
