Site~Rite

8 Ultrasound System Page 39

Well Aligned – In-Plane Box and Needle Trajectory are Green

Probe View Ultrasound Image

In-Plane Box View

Needle

Shaft

Needle

Trajectory

Misaligned – In-Plane Box and Needle Trajectory are Violet

Probe View Ultrasound Image

In-Plane Box View

Needle

Shaft

Needle

Trajectory
