AW00097603000 Color Creation and Enhancement
Basler aviator GigE 119
Camera.ProcessedRawEnable.SetValue( true );
// Select the matrix color transformation type
Camera.ColorTransformationSelector.SetValue
( ColorTransformationSelector_RGBtoRGB );
// Set the light source selector so that no correction will be done
Camera.LightSourceSelector.SetValue
( LightSourceSelector_Off );
// Set the light source selector for tungsten lighting
Camera.LightSourceSelector.SetValue
( LightSourceSelector_Tungsten );
// Set the light source selector for daylight (at about 5000K)
Camera.LightSourceSelector.SetValue
( LightSourceSelector_Daylight );
// Set the light source selector for daylight (at about 6500K)
Camera.LightSourceSelector.SetValue
( LightSourceSelector_Daylight6500K );
// Set the matrix correction factor
Camera.ColorTransformationMatrixFactor.SetValue( 0.50 );
You can also use the Basler pylon Viewer application to easily set the parameters.
For more information about the pylon API and the pylon Viewer, see Section 3 on page 21.
8.3.3.1 The Custom Light Source Setting
The RGB to RGB color matrix conversion for each pixel is performed by multiplying a 1 x 3 matrix
containing R, G, and B color values with a 3 x 3 matrix containing correction values. Each column
in the 3 x 3 matrix can be populated with values of your choice. In other words:
Where Gain00, Gain01, etc. are settable values.
The "Custom" setting for the Light Source Selector parameter is intended for use
by someone who is thoroughly familiar with matrix color transformations. It is
nearly impossible to enter correct values in the conversion matrix by trial
and error.
