Standard Features AW00097603000
190 Basler aviator GigE
10.9 Error Codes
The camera can detect several user correctable errors. If one of these errors is present, the camera
will set an error code and will flash both the yellow and green LEDs in the LED indicator.
When the camera detects a user correctable error, it sets the appropriate error code in an error
memory. If two or three different detectable errors have occurred, the camera will store the code for
each type of error that it has detected (it will store one occurrence of the each code no matter how
many times it has detected the corresponding error).
You can use the following procedure to check the error codes:
Read the value of the Last Error parameter. The Last Error parameter will indicate the last error
code stored in the memory.
Execute the Clear Last Error Command to clear the last error code from the memory.
Continue reading and clearing the last error until the parameter indicates a No Error code.
Code Condition Meaning
0 No Error The camera has not detected any errors since the last time that the error memory
was cleared.
1 Overtrigger An overtrigger has occurred.
The user has applied an acquisition start trigger to the camera when the camera
was not in a waiting for acquisition start condition.
Or, the user has applied a frame start trigger to the camera when the camera was
not in a waiting for frame start condition.
2 User set
load
An error occurred when attempting to load a user set.
Typically, this means that the user set contains an invalid value. Try loading a
different user set.
3 Invalid
Parameter
A parameter is set out of range or in an otherwise invalid manner.
4Over
Temperature
The camera has stopped image acquisition due to overheating. Provide adequate
cooling to the camera.
Table 11: Error Codes
