Basler GigE CAMERAS User Manual

Specifications, Requirements, and Precautions AW00097603000
10 Basler aviator GigE
1.4.3 Maximum Lens Thread Length on Color Cameras
The C-mount lens adapter on color models of the camera is normally equipped with an internal IR
cut filter. As shown in Figure 5, the length of the threads on any lens you use with a color camera
must be less than 7.5 mm. If a lens with a longer thread length is used, the IR cut filter will be
damaged or destroyed and the camera will no longer operate.
C-mount color cameras that do not include an internal IR cut filter are available on
request.
Monochrome cameras are not normally equipped with an internal IR cut filter,
however, they can be equipped with an internal filter on request.
< 7.5 mm
Not to Scale
IR Cut Filter
Lens Adapter
C-mount Lens
Fig. 5: Maximum Lens Thread Length on Color Cameras
