AW00097603000 Standard Features
Basler aviator GigE 175
10.7.3.1 Assignment of an Auto Function to an Auto Function AOI
By default, the Gain Auto and the Exposure Auto auto functions are assigned to Auto Function AOI
1 and the Balance White Auto auto function is assigned to Auto Function AOI 2. The assignments
can, however, be set as desired. For example, the Balance White Auto auto function can be
assigned to Auto Function AOI 1 or all auto functions can be assigned to the same Auto Function
AOI.
Limitation: For the purpose of making assignments, the Gain Auto and the Exposure Auto auto
functions are always considered as a single "Intensity" auto function and therefore the Auto
Function AOI assignment is always identical for both auto functions. For example, if you assign the
"Intensity" auto function to Auto Function AOI 2 the Gain Auto and the Exposure Auto auto functions
are both assigned to Auto Function AOI 2. This does not imply, however, that the Gain Auto and the
Exposure Auto auto functions must always be used at the same time.
You can assign auto functions to Auto Function AOIs from within your application software by using
the pylon API.
As an example, the following code snippet illustrates using the API to assign the Gain Auto and
Exposure Auto auto function - considered as a single "Intensity" auto function - and the Exposure
Auto auto function to Auto Function AOI 1.
The snippet also illustrates disabling the unused Auto Function AOI 2 to avoid assigning any auto
function to more than one Auto Function AOI.
// Select Auto Function AOI 1
// Assign auto functions to the selected Auto Function AOI
Camera.AutoFunctionAOISelector.SetValue( AutoFunctionAOISelector_AOI1 );
Camera.AutoFunctionAOIUsageIntensity.SetValue( true );
Camera.AutoFunctionAOIUsageWhiteBalance.SetValue( true );
// Select the unused Auto Function AOI 2
// Disable the unused Auto Function AOI
Camera.AutoFunctionAOISelector.SetValue( AutoFunctionAOISelector_AOI2 );
Camera.AutoFunctionAOIUsageIntensity.SetValue( false );
Camera.AutoFunctionAOIUsageWhiteBalance.SetValue( false );
You can also use the Basler pylon Viewer application to easily set the parameters.
We strongly recommend that you do not assign an auto function to more than one
Auto Function AOI even though this can be done.
