Basler GigE CAMERAS User Manual

AW00097603000 Specifications, Requirements, and Precautions
Basler aviator GigE 9
1.4.2 Sensor Positioning Accuracy
The sensor positioning accuracy is as shown Figure 4.
17.5
Photosensitive
surface of the
sensor
± 0.025
(This is the sensor tilt tolerance. It applies to every point on the
photosensitive surface and is relative to the center of the die.)
= Reference plane
±
1
°
Fig. 4: Sensor Positioning Accuracy (in mm unless otherwise noted)
