Standard Features AW00097603000
216 Basler aviator GigE
The AsyncAdvance command has not yet become effective because of the assumed
associated delay.
When the next frame start trigger is received, the camera checks the active set and uses it for
the image acquisition. The parameter values of sequence set 0 are used.
The AsyncAdvance command has not yet become effective because of the assumed
associated delay.
When the AsyncAdvance command becomes effective, the camera happens to be in "waiting
for frame start trigger" status. The parameter values of the next sequence set, i.e. of sequence
set 1, are loaded into the active set. Note that the camera briefly exits the "waiting for frame
start trigger" status while the parameter values of sequence set 1 are loaded into the active set
(see also Figure 50).
When the next frame start trigger is received, the camera checks the active set and uses it for
the image acquisition. The parameter values of sequence set 1 are used.
When the next frame start trigger is received, the camera checks the active set and uses it for
the image acquisition. The parameter values of sequence set 1 are used.
When the next frame start trigger is received, the camera checks the active set and uses it for
the image acquisition. The parameter values of sequence set 1 are used.
An AsyncRestart command is sent. After some delay, the parameter values of sequence set 0
will be loaded into the active set. It is assumed here that the delay between sending the
AsyncRestart command and it becoming effective will allow the acquisition of two more
images.
When the next frame start trigger is received, the camera checks the active set and uses it for
the image acquisition. The parameter values of sequence set 1 are used.
The AsyncRestart command has not yet become effective because of the assumed associated
delay.
When the next frame start trigger is received, the camera checks the active set and uses it for
the image acquisition. The parameter values of sequence set 1 are used.
The AsyncRestart command has not yet become effective because of the assumed associated
delay.
When the AsyncRestart command becomes effective, the camera happens to be in "waiting for
frame start trigger" status. The parameter values of sequence set 0 are loaded into the active
set. Note that the camera briefly exits the "waiting for frame start trigger" status while the
parameter values of sequence set 1 are loaded into the active set (see also Figure 50).
Make sure not to send a frame start trigger while the parameter values of a
sequence set are loaded into the active set. During this period, the camera will
not wait for a frame start trigger and any frame start trigger will be ignored.
Make sure to only send a frame start trigger when the camera is in "waiting for
frame start trigger" status.
For information about possibilities of getting informed about the "waiting for
frame start trigger" status, see the Acquisition Monitoring Tools section.
