Basler scout GigE User Manual

Image Acquisition Control AW00011916000
118 Basler scout GigE
9.5 The Frame Start Trigger in
Standard Mode
For more information about standard mode and legacy mode and how to set them, see Section 9.1
on page 103.
The frame start trigger is used to begin frame acquisition. Assuming that the camera is in a "waiting
for frame start trigger" acquisition status, it will begin a frame acquisition each time it receives a
frame start trigger signal.
Note that in order for the camera to be in a "waiting for frame start trigger" acquisition status:
 The Acquisition Mode parameter must be set correctly.
 A proper Acquisition Start command must be applied to the camera.
 A proper acquisition start trigger signal must be applied to the camera (if the Trigger Mode
parameter for the acquisition start trigger is set to on).
For more information about the Acquisition Mode parameter and about Acquisition Start and
Acquisition Stop commands, see Section 9.2 on page 105 and Section 9.3 on page 109.
For more information about the acquisition start trigger, and about the acquisition status, see
Section 9.2 on page 105 and Section 9.4 on page 111.
Referring to the use case diagrams that appear in Section 9.8 on page 144 can help you
understand the explanations of the frame start trigger.
This section only applies if the standard mode is enabled for image acquisition
control.
When the camera is started for the first time after delivery from the factory the
image acquisition control will not be in standard mode but in legacy mode.
Use the legacy mode only if you want to operate the camera together with
previous cameras not featuring the standard mode.
