7.2 Connector Pin Assignments
and Numbering
7.2.1 12-pin Receptacle Pin Assignments
The 12 pin receptacle is used to access the two physical input lines and four physical output lines
on the camera. It is also used to supply power to the camera. The pin assignments for the
receptacle are shown in Table 7.
Pin Designation
1 Camera Power Gnd *
2 Camera Power Gnd *
3 I/O Input 1
4 I/O Input 2
5 I/O Input Gnd
6 I/O Output 1
7 I/O Output 2
8 Camera Power VCC **
9 Camera Power VCC **
10 I/O Output VCC
11 I/O Output 3
12 I/O Output 4
Table 7: Pin Assignments for the 12-pin Receptacle
* Pins 1 and 2 are tied together inside of the camera.
** Pins 8 and 9 are tied together inside of the camera.
To avoid a voltage drop when there are long wires between your power suppy and
the camera, we recommend that you provide camera power VCC through
separate wires between your power supply and pins 8 and 9 on the camera. We
also recommend that you provide camera power ground through separate wires
between your power supply and pins 1 and 2 on the camera.
