Basler scout GigE User Manual

AW00011916000 Specifications, Requirements, and Precautions
Basler scout GigE 29
1.5.2 90° Head Housing
The camera housing conforms to protection class IP30 assuming that the lens mount is covered by
a lens or by the cap that is shipped with the camera.
1.5.2.1 Camera Dimensions and Mounting Points
In scout cameras with the 90° head housing the camera’s direction of view is at right angle to the
direction of view of standard scout cameras.
The cameras are manufactured with high precision. Planar, parallel, and angular sides guarantee
precise mounting with high repeatability.
The dimensions in millimeters for cameras equipped with a standard C-mount lens adapter are as
shown in Figure 25.
Camera housings are equipped with four mounting holes on the top and four mounting holes on the
bottom as shown in the drawings. In addition, there are four mounting holes in the front module (4x
M3; 4.5 mm deep).
For optimum accuracy in the positioning of the camera's optical axis, we
recommend using the front module reference plane (see the figure in the Sensor
Positioning Accuracy section) as mounting surface.
