Specifications, Requirements, and Precautions AW00011916000
18 Basler scout GigE
1.4 Spectral Response for Color Cameras
The following graphs show the spectral response for each available color camera model
Fig. 11: scA640-70gc Spectral Response
The spectral response curves exclude lens characteristics, light source
characteristics, and IR cut filter characteristics.
To obtain best performance from color models of the camera, use of a dielectric
IR cut filter is recommended. The filter should transmit in a range from 400 nm to
640 ... 660 nm, and it should cut off from 640 ... 660 nm to 1100 nm.
A suitable IR cut filter is included in the standard C-mount lens adapter on color
models of the camera. (An IR cut filter is not included in the optional CS-mount
adapter).
