Basler scout GigE User Manual

AW00011916000 Standard Features
Basler scout GigE 275
12.6 Binning (All Models Except scA750-60)
Binning increases the camera’s response to light by summing the charges from adjacent pixels into
one pixel. Two types of binning are available: vertical binning and horizontal binning.
With vertical binning, adjacent pixels from 2 lines, 3 lines, or a maximum of 4 lines in the imaging
sensor array are summed and are reported out of the camera as a single pixel. Figure 81 illustrates
vertical binning.
Fig. 81: Vertical Binning
With horizontal binning, adjacent pixels from 2 columns, 3 columns, or a maximum of 4 columns are
summed and are reported out of the camera as a single pixel. Figure 82 illustrates horizontal bin-
ning.
Fig. 82: Horizontal Binning
 The binning feature is only available on the monochrome cameras.
 The binning feature is not available on scA750-60 cameras.
Vertical Binning by 2 Vertical Binning by 3 Vertical Binning by 4
Horizontal Binning by 2 Horizontal Binning by 3 Horizontal Binning by 4
