Fig. 25: Mechanical Dimensions (in mm) for Cameras (90° Head) with the Standard C-mount Lens Adapter
32.1
2 x M3; 4.5 deep
2 x M3; 4 deep
3.25
51.15
3.75
2 x M3; 4.8 deep
32.1
15.6
3.1
ca. 15.4
2 x M3; 4.5 deep
97
91.65
Photosensitive
surface of the
sensor
72.65
Ø
28.5
29
3.25
86.3
2 x M3; 3.5 deep
2 x M3; 4.5 deep
20
6.1
2 x M2; 4.5 deep
To p
Bottom
