Basler scout GigE User Manual

Specifications, Requirements, and Precautions AW00011916000
4 Basler scout GigE
Specification scA750-60gm/gc scA780-54gm/gc
Sensor Size
(H x V pixels)
gm: 752 x 480
gc: 750 x 480
gm: 782 x 582
gc: 780 x 580
Sensor Type Aptina MT9V022 (formerly known as the
Micron MT9V022)
Sony ICX415 AL/AQ
Progressive scan CMOS Progressive scan CCD
Optical Size 1/3" 1/2"
Pixel Size 6.0 µm x 6.0 µm 8.3 µm x 8.3 µm
Max. Frame Rate
(at full resolution)
64.9 fps 55 fps
Mono/Color All models available in mono or color
Data Output Type Fast Ethernet (100 Mbit/s) or Gigabit Ethernet (1000 Mbit/s)
Pixel Data Formats Mono Models:
Mono 8 ( = DCAM Mono 8)
YUV 4:2:2 Packed
( = DCAM YUV 4:2:2)
YUV 4:2:2 (YUYV) Packed
Mono 8 ( = DCAM Mono 8)
Mono 16 ( = DCAM Mono 16)
Mono 12 Packed
YUV 4:2:2 Packed ( = DCAM YUV
4:2:2)
YUV 4:2:2 (YUYV) Packed
Color Models:
Mono 8 ( = DCAM Mono 8)
Bayer RG 8 ( = DCAM Raw 8)
RGB 8 Packed
YUV 4:2:2 Packed
( = DCAM YUV 4:2:2)
YUV 4:2:2 (YUYV) Packed
Mono 8 ( = DCAM Mono 8)
Bayer BG 8 ( = DCAM Raw 8)
Bayer BG 16 ( = DCAM Raw 16)
Bayer BG 12 Packed
RGB 8 Packed
YUV 4:2:2 Packed
( = DCAM YUV 4:2:2)
YUV 4:2:2 (YUYV) Packed
ADC Bit Depth 10 bits 12 bits
Synchronization Via external trigger signal or via software
Exposure Control Programmable via the camera API
Camera Power
Requirements
+12 VDC (-5 %) to +24 VDC (+5 %), < 1% ripple
2.5 W @ 12 V 3.0 W @ 12 V
I/O Ports 2 opto-isolated input ports and 4 opto-isolated output ports
Lens Adapter C-mount (CS-mount optional)

Basler scout GigE Specifications

General
