Specification scA1000-30gm/gc scA1300-32gm/gc scA1390-17gm/gc
Sensor Size
(H x V pixels)
gm: 1034 x 779
gc: 1032 x 778
gm: 1296 x 966
gc: 1294 x 964
gm: 1392 x 1040
gc: 1390 x 1038
Sensor Type Sony ICX204 AL/AK Sony ICX445 ALA/AQA Sony ICX267 AL/AK
Progressive scan CCD
Optical Size 1/3" 1/3" 1/2"
Pixel Size 4.65 µm x 4.65 µm 3.75 µm x 3.75 µm 4.65 µm x 4.65 µm
Max. Frame Rate
(at full resolution)
31 fps 32 fps 17 fps
Mono/Color All models available in mono or color
Data Output Type Fast Ethernet (100 Mbits/s) or Gigabit Ethernet (1000 Mbits/s)
Pixel Data Formats Mono Models:
Mono 8 ( = DCAM Mono 8)
Mono 16 ( = DCAM Mono 16)
Mono 12 Packed
YUV 4:2:2 Packed ( = DCAM YUV 4:2:2)
YUV 4:2:2 (YUYV) Packed
Color Models:
Mono 8 ( = DCAM Mono 8)
Bayer BG 8 ( = DCAM Raw 8)
Bayer BG 16 ( = DCAM Raw 16)
Bayer BG 12 Packed
RGB 8 Packed
YUV 4:2:2 Packed ( = DCAM YUV 4:2:2)
YUV 4:2:2 (YUYV) Packed
ADC Bit Depth 12 bits
Synchronization Via external trigger signal or via software
Exposure Control Programmable via the camera API
Camera Power
Requirements
+12 VDC (-5 %) to +24 VDC (+5 %), < 1% ripple
3.0 W @ 12 V 3.5 W @ 12 V 3.5 W @ 12 V
I/O Ports 2 opto-isolated input ports and 4 opto-isolated output ports
Lens Adapter C-mount (CS-mount optional)
