AW00011916000 Standard Features
Basler scout GigE 243
The following parameters are included in each sequence set:
* This parameter is individually available for timer 1, timer 2, timer 3, and timer 4.
**This parameter is only available in auto sequence advance mode.
Sequence Set Configuration
Before the sequencer feature can be used you must populate the sequence sets with the parameter
values of the sequence parameters and store the sequence sets in the camera’s memory. Each
sequence set is identified by a sequence set index number starting from zero. After storing, the
sequence sets are available for use by the sequencer feature.
Some sequence advance modes require the storing of additional settings, for example, the total
number of sequence sets you want to use, the number of consecutive uses of a sequence set or
the source to control sequence set advance. For details about populating sequence sets and
making related settings see the sections below explaining the sequence advance modes.
Exposure Time Digital Shift
Enable Acquisition Frame Rate LUT Enable
Acquisition Frame Rate Color Transformation Value
Width Color Transformation Matrix Factor
Height Color Adjustment Enable
X Offset Color Adjustment Hue
Y Offset Color Adjustment Saturation
Center X Chunk Mode Active
Center Y Chunk Enable
Binning Horizontal Timer Delay*
Binning Vertical Timer Duration*
Pixel Format Timer Delay Timebase*
Test Image Timer Duration Timebase*
Gain Sequence Set Executions**
Processed Raw Enable
Black Level
When the sequencer feature is enabled, the sequence parameter values of the
current sequence set cannot be read or changed using the pylon API or the pylon
Viewer. Only those sequence parameter values will be displayed that were active
before the sequencer was enabled. You will not be able to "see" the parameter
values set by the current set.
Make sure the sequencer feature is disabled when configuring sequence sets.
