AW00011916000 Standard Features
Basler scout GigE 257
Note also that the camera briefly exits the "waiting for frame start trigger" status while an input
line changes its state. This happened when input line 1 changed its state before the second
frame start trigger was received (see also Figure 77).
When the next frame start trigger was received, the camera checks the state of input line 1.
Input line 1 is found to be low and therefore no new sequence parameter values are loaded
into the active set. The parameter values of sequence set 1 are used for the image acquisition.
When the next frame start trigger was received, the camera checks the state of input line 1.
Input line 1 is found to be low and therefore no new sequence parameter values are loaded
into the active set. The parameter values of sequence set 1 are used for the image acquisition.
When the next frame start trigger was received, the camera checks the state of input line 1.
Input line 1 is found to be high and therefore the parameter values of the next sequence set
are loaded into the active set. The parameter values of sequence set 2 are used for the image
acquisition.
When the next frame start trigger was received, the camera checks the state of input line 1.
Input line 1 is found to be high and therefore the parameter values of the next sequence set
are loaded into the active set. The parameter values of sequence set 3 are used for the image
acquisition.
When the next frame start trigger was received, the camera checks the state of input line 1.
Input line 1 is found to be high and therefore the parameter values of the next sequence set
are loaded into the active set. The parameter values of sequence set 4 are used for the image
acquisition.
When the next frame start trigger was received, the camera checks the state of input line 1.
Input line 1 is found to be high and therefore the parameter values of the next sequence set
are loaded into the active set. The parameter values of sequence set 5 are used for the image
acquisition.
When the next frame start trigger was received, the camera checks the state of input line 1.
Input line 1 is found to be low and therefore no new sequence parameter values are loaded
into the active set. The parameter values of sequence set 5 are used for the image acquisition.
The camera has cycled once through the complete sequence set cycle.
When the next frame start trigger was received, the camera checks the state of input line 1.
Input line 1 is found to be high and therefore the parameter values of the next sequence set
are loaded into the active set. The parameter values of sequence set 0 are used for the image
acquisition.
Make sure not to send a frame start trigger while the input line changes its
state. During this period, the camera will not wait for a frame start trigger and
any frame start trigger will be ignored.
Make sure to only send a frame start trigger when the camera is in "waiting for
frame start trigger" status.
For information about possibilities of getting informed about the "waiting for
frame trigger" status, see the Acquisiton Monitoring Tools section.
