BeagleBone Black - 9.0 BeagleBone Black Mechanical; 9.1 Dimensions and Weight

REF: BBONEBLK_SRM
BeagleBone Black System
Reference Manual
Rev A5.2
Page 101 of 108
9.0 BeagleBone Black Mechanical
9.1 Dimensions and Weight
Size: 3.5” x 2.15” (86.36mm x 53.34mm)
Max height: .187” (4.76mm)
PCB Layers: 6
PCB thickness: .062”
RoHS Compliant: Yes
Weight: 1.4 oz
