7.4 USB Host
There is a single USB Host connector on the board and is shown in Figure 47 below.
Figure 47. USB Host Connector
The port is USB 2.0 HS compatible and can supply up to 500mA of current. If more
current or ports is needed, then a HUB can be used.
USB Host
Connector
