4.2 BeagleBone Black Features and Specification
This section covers the specifications and features of the board and provides a high level
description of the major components and interfaces that make up the board.
Table 2 provides a list of the features.
Table 2. BeagleBone Black Features
Feature
Processor
Sitara AM3359AZCZ100
1GHz, 2000 MIPS
Graphics Engine
SGX530 3D, 20M Polygons/S
SDRAM Memory
512MB DDR3L 606MHZ
Onboard Flash
2GB, 8bit Embedded MMC
PMIC
TPS65217C PMIC regulator and one additional LDO.
Debug Support
Optional Onboard 20-pin CTI JTAG, Serial Header
Power Source
miniUSB USB or DC
Jack
5VDC External Via Expansion
Header
PCB
3.4” x 2.1”
6 layers
Indicators
1-Power, 2-Ethernet, 4-User Controllable LEDs
HS USB 2.0 Client Port
Access to USB0, Client mode via miniUSB
HS USB 2.0 Host Port
Access to USB1, Type A Socket, 500mA LS/FS/HS
Serial Port
UART0 access via 6 pin 3.3V TTL Header. Header is populated
Ethernet
10/100, RJ45
SD/MMC Connector
microSD , 3.3V
User Input
Reset Button
Boot Button
Power Button
Video Out
16b HDMI, 1280x1024 (MAX)
1024x768,1280x720,1440x900
w/EDID Support
Audio
Via HDMI Interface, Stereo
Expansion Connectors
Power 5V, 3.3V , VDD_ADC(1.8V)
3.3V I/O on all signals
McASP0, SPI1, I2C, GPIO(65), LCD, GPMC, MMC1, MMC2, 7
AIN(1.8V MAX), 4 Timers, 3 Serial Ports, CAN0,
EHRPWM(0,2),XDMA Interrupt, Power button, Expansion Board ID
(Up to 4 can be stacked)
Weight
1.4 oz (39.68 grams)
Power
Refer to Section 6.1.7
